Valtra T194 User Manual

2.6 Controls on the right-hand side
2.6.1 Driving controls
AUTO
CONTROL
STOP
1
2
4
6
7
8
9
10
11
12
13
14
15
3
5
16
GUID-8C1CEF16-6823-4D2C-A55C-FF1A3A6A4F35
1. Emergency brake button
2. Push button for EcoPower (optional)
3. Switch for four-wheel drive (4WD)
4. Switch for differential lock
5. Push button for shifting automatics
6. QuickSteer control knob (optional)
7. QuickSteer activation button (optional)
8. Auto-Guide steering valve on/off button (optional)
9. Auto-Guide receiver on/off button (optional)
10. Control stop switch (optional)
11. HiShift push button
12. Powershift push button
13. Range speed push button
14. Auto-Guide remote activation button (optional)
15. Hand throttle
16. Engine RPM memory button
2. Instruments and controls
- 43 -

Valtra T194 Specifications

General

Max Speed	50 km/h
Wheelbase	2995 mm
Cylinders	4
Engine Type	AGCO Power
Hydraulic System	Load-sensing
