3.17.2.7 Using the rear power take-off automatic start/stop
The rear power take-off (PTO) automatic start/stop is useful in headland turns, for
example, where the implement needs to be raised temporarily and then lowered
back.
2
AUTO
AUTO
CONTROL
1
GUID-D168061B-DB5A-4F18-8E3C-4DCBE6E7DD2D
1. Lifting/stop/lowering switch
2. Button for rear PTO automatic start/stop
Activate the PTO automatic start/stop by pressing the button for rear PTO
automatic start/stop.
You can activate the PTO automatic start/stop only if the PTO is engaged
and the linkage is not in the transport position.
The light in the button is lit when the PTO automatic start/stop is activated.
The PTO is stopped automatically when you have activated the automatic
start/stop and set the lift/stop/lower switch to the transport position and when
the linkage has raised the lower links to the position of at least 70% of the
maximum lifting height. After an automatic stop, the light on the button and
the display symbol start to blink, indicating that the PTO automatic start is
standing by.
The automatic start takes place only if the PTO has been stopped with the
automatic start/stop. The PTO starts automatically if the driving speed is
between 1 and 25 km/h, the linkage is lowered with the lifting/stop/lowering
switch and the lower links have been lowered to 90% of the maximum lifting
height.
3. Operation
- 214 -
