GUID-2C39D216-1CC8-4FE9-B3AF-3588CED6DD57
1. Fuel cooler
2. Air conditioning cooler (extra equipment)
3. Front power take-off (PTO) oil cooler (extra equipment)
4. Protection plate
5. Engine coolant radiator
6. Engine intake air cooler
7. Transmission oil cooler
1. Open the engine cover.
2. Lift the air conditioning cooler (extra equipment) to the upper position.
The air condition cooler is fastened with two screws.
3. Open the protection plate on the right-hand side.
The protection plate is locked with a knurled head screw. Opening the
protection makes cleaning easier.
4. Clean the radiators using compressed air or flush them with water.
When cleaning, use the air pressure, a water hose (not a pressure washer)
or a soft brush. Be careful not to damage the cores.
4. Maintenance
- 271 -
