WARNING: According to law, the operator has to ensure that all
relevant precautions are taken (lockings secured etc.).
GUID-70352EBA-D71D-4B2C-9E80-8E7F322612C6
1. Short towing device frame
2. Towing device frame
3. Universal towing device frame
4. Towing device frame with a fixed 80–mm ball coupling
5. Towing device frame with a fixed Piton-Fix pin
6. Drawbar (optional)
7. Drawbar pin locking
8. Locking
Locking to the trailer must be secured.
3.21.7.1 Adjusting the jaw height
The height of mechanical and automatic jaws is adjusted in the same way.
WARNING: You cannot change the jaw height if the lever is broken or
dirty. The jaw must be locked and secured every time the height is
changed.
3. Operation
- 239 -
