8
Model Code Page
11. Layout
8. 11. 1990
6000--8750 110 2
3. Code designation
Three---digit code designations are used to distinguish the different document groups for the respective components . The same
code is also used in the Time List as a reference to the text in this Manual. The code designation numbers appear both in the box at
thetopofthepageandalsointheheadings.
Example: Code 410:
--- Group: Power transmission (4)
--- Component: Clutch (41)
--- Document group: General (410)
4. Page numbers
The instructions for all components are numbered in consecutive order in the right---hand box at the top of the page. The page
numbers begin with page 1 for each component.
41. Clutch
15. 5. 1993
Model Code
Page
6100---8400 410 1
8. 11. 1990
5. Date
At the top of each page there are two boxes for dates. In the case of a revised issue, the date of the earlier issue is printed in the
crossed---overboxandthedateofthecurrentissueisprintedinthe”real”datebox.
6. Model
At the top of each page the tractor model for which the page is valid is indicated.
7. Additions and amendments of the service manual
New and up---dated pages will be continually added to the service manual. The new pages should be inserted as indicated by the
code: the first digit (also t he first digit on the index leaf) indicated the group:
--- the two first digits indicate the component or sub---group
--- the third digit indicat es the document group for the respective components
--- the page number indicates the definite position of the page within the service manual
If there are two pages with the same code and page number the page with the later date in the date box (and the old date in the
crossed---over box) is valid (or the current page).
N.B. Fitting instructions for extra equipment are inserted into the service manual at the end of group concerned (E.g. code 39 is
inserted at the end of group 30).
