32
Model Code Page
21. Engine
1. 11. 1998
6000--8750
210 10
1. 1. 1994
Special tools
Order no Description
1 9051 73100 Puller for cylinder liner
2 9101 65600
*
) Milling cutter for cylinder liner seat
3 9052 46400 Centring tool for flywheel housing
4 9052 46300 Drift for fitting rear crankshaft seal
5 9030 15200 Drift for fitting front crankshaft seal
6 9052 46620 Drift for 40 mm cap plug
7 9052 46650 Drift for 16 mm cap plug
8 9025 87400 Drift for fitting camshaft cup plug
9 9101 66300
*
) Presstoolforcylinderliner
10 9025 79200 Holder for dial gauge
11 9101 66100
*
) T---handle for valve seat milling cutter
12 9101 71100
*
) Milling cutter for facing exhaust valve seat
13 9101 65502
*
) Milling cutter for exhaust valve seat
14 9101 65503
*
) Inner milling cut ter for exhaust valve seat
15. 9101 75800
*
) Milling cutter for facing inlet valve seat
16 9101 65505
*
) Milling cutter for inlet valve seat
17 9101 65506
*
) Inner milling cut ter for inlet valve seat
18 9101 66200
*
) Lever for c o mpressing valve spring
19 9052 47200 Counter nut for lever above
20 9101 66000
*
) Milling tool for injector seat
21 9052 46660 Drift for 36 mm cup plug
22 9101 65800
*
) Drift for removing valve guide
23 9101 65900
*
) Drift for fitting valve guide
24 9024 55800 Spanner for crankshaft nut, 634---engines
25 9101 65700
*
) Spanner for crankshaft nut
26 9052 48800 Puller for crankshaft gears
27 9020 01100 Conical sleeve for fitting pistons
28 9025 98900 Drift for fitting dust cover, crankshaft front seal
29 9025 98800 Drift for fitting tension pin in timing gear casing
30 9025 98700 Drift for fitting tension pins in timing gear casing and flywheel housing
31 8366 62022 Electronical device for checking injection timing on E---engines
*
) New tools for 20---series engines. Other tools are the same as for engines on 505---905 tractors.
1 2
3
4
6 7
8
9
10
5
