VAMP 130 Overcurrent and earth-fault relay
Operation and Configuration
VAMP Ltd
18
Vamp 24h support phone : +358 (0)40 573 6316 VM130.EN003
3. Use the ENTER key twice to move to give the operator
password. Use the ENTER key to confirm the password.
4. Use the UP and DOWN key to change the setting value and
use the RIGHT and LEFT key to move from digit to digit.
5. Use the ENTER key to confirm the function or push the
LEFT key for >2 s to cancel the function.
6. Push the LEFT key twice to return to the main menu.
Figure 5.1-1 Changing parameters.
5.2. Enabling and disabling protection
functions (ENABLE)
Via the submenus of the ENABLE menu, all the protection
functions can be enabled (ON) or disabled (OFF):
ENABLE I
• Overcurrent stages (I> I>>, I>>> and I2>)
ENABLE Io
• Residual current stages (Io>, Io>>, Io>>>)
Ena CBFP
• Circuit Breaker Failure Protection stage (CBFP)
