VAMP 130 - Trip Contacts (T1 and T2); Alarm Contacts (A1; Local Serial Communication Port; Connectors

VAMP Ltd Overcurrent and earth-fault relay
Technical Description
VAMP 130
VM130.EN003 Vamp 24h support phone : +358 (0)40 573 6316
37
5.1.4. Trip contacts (T1 and T2)
Number of contacts 2 making contacts
Rated voltage 250 V ac
Continuous carry 5 A
Max. making current 15 A
Breaking capacity, AC 2 000 W/VA
Breaking capacity, DC (L/R=40ms) 50 W
Contact material AgNi 90/10
5.1.5. Alarm contacts (A1...A3) and IF
Number of contacts 3 making contacts (relays A1...A3)
1 making contact (relay IF)
Rated voltage 250 V ac
Continuous carry 5 A
Breaking capacity 1 500 W/VA
Contact material AgSnO
2
5.1.6. Local serial communication port
Number of ports 1 on front panel
Electrical connection RS 232
Data transfer rate 2 400…38 400 b/s
5.1.7. Connectors
Connector X1
Max. torque 1.2 Nm
AWG 14 - 10
Connectors X2 and X4
Max. torque 0.5 – 0.6 Nm
AWG 24 - 12
5.2. Tests and environmental conditions
5.2.1. Disturbance tests (EN 50263)
Emission
- Conducted (EN 55022) 0.15 - 30 MHz
- Emitted (EN 55022) 30 - 1 000 MHz
