Immunity
- Static discharge (ESD) EN 61000-4-2, class III
6 kV contact discharge
8 kV air discharge
- Fast transients (EFT) EN 61000-4-4, class III
2 kV, 5/50 ns, 5 kHz, +/-
- Surge EN 61000-4-5, class III
1 kV, 1.2/50 Ps, common mode
2 kV, 1.2/50 Ps, differential mode
- Conducted RF field EN 61000-4-6
0.15 - 80 MHz, 10 V/m, 80% AM (1 kHz)
- Emitted RF field EN 61000-4-3
80 - 1000 MHz, 10 V/m, 80% AM (1 kHz)
- GSM test EN 61000-4-3
900 MHz, 10 V/m, pulse modulated
1 MHz burst IEC 60255-22-1
1 kV, differential mode
2,5 kV, common mode
Voltage interruption IEC 60255-11
5.2.2. Test voltages
Insulation test voltage (IEC 60255-5) 2 kV, 50 Hz, 1 min
Surge voltage (IEC 60255-5)
5 kV, 1,2/50 Ps, 0,5 J
5.2.3. Mechanical tests
Vibration (IEC 60255-21-1) 10 - 60 Hz, amplitude ±0.035 mm
60 - 150 Hz, acceleration 0.5g
sweep rate 1 octave/min
20 periods in X-, Y- and Z axis direction
Shock (IEC 60255-21-1) half sine, acceleration 5 g, duration 11 ms
3 shocks in X-, Y- and Z axis direction
5.2.4. Environmental conditions
Operating temperature -10 to +55 ×C
Transport and storage temperature -40 to +70 ×C
Relative humidity < 75% (1 year, average value)
< 90% (30 days per year, no condensation
permitted)
5.2.5. Casing
Degree of protection (IEC 60529) IP20
Dimensions (W x H x D) 99 x 155 x 225 mm
Weight 2.3 kg
