VAMP 130 Overcurrent and earth-fault relay
Operation and Configuration
VAMP Ltd
4
Vamp 24h support phone : +358 (0)40 573 6316 VM130.EN003
2. User interface
2.1. General
The VAMP 130 relay can be controlled in two ways:
Locally with the push-buttons on the relay front panel
Locally with a PC connected to the serial port on the relay
front panel
2.2. Local panel
Figure 2.2-1 below shows the location of the components of the
local user interface on the front panel of the relay.
VY 055 A
1
2
3
4
3
Figure 2.2-1 Relay front panel.
1. Alpha-numerical LED display
2. Key pad
3. LED indicators
4. RS 232 serial communication port for a PC
