4.3 Mounting instructions for flush mount unit
A Standardpattressbox.
B
C
Mountingplateisattachedtothepattressusingthescrewssupplied(C).
Ensurethecorrectspacers(B)havebeenusedtobridgethegapbetweenthemountingplateandthefixing
wingsofthepattressboxtoavoidthemountingplatebeingdistorted.
D Placethereader/keypadontothesurfacemountcollarandclipdownintoplace.
E Usethesecurityscrewsuppliedtoattachedtheunittotheflushmountcollar.
F Placethecapontotheunitandpushfirmlyinplace.

ACT 5e Digital Keypad – Installation Manual Wiring and Mounting Diagrams
© Vanderbilt 2018 10
A-100443
31.01.2018
