1 Installation Overview
l Alwaysremembertofactorydefaultthecontrollerbeforeyoustartprogramming.
l Alwaysremembertoplacethesuppliedvaristoracrosstheterminalsofthedoorstrikecoiltoprotect
therelaycontacts.
l NeverusetheonboardrelaytoswitchACmainsvoltage.Anexternalrelayisolatedelectricallyfrom
theACT5eDigitalKeypadshouldbeusedforthispurpose.
l Don’tforgettochangetheprogrammingcodetosomethingknownonlytoyourself.

Aswithanyaccesscontrolsystem,alwaysensurethatthereisanalternatemeansofescapeinthe
eventoftheunitfailingtooperateduetopowerlossorintheeventoffire.
© Vanderbilt 2018 4
A-100443
31.01.2018
