1 Overview
ThisguidedescribestheinstallationoftheACTpro1520eand1500econtrollers.
TheACTpro1500eControllerisasingledoorIPcontrollerthatrequiresanexternal12Vor24Vpower
supply.
TheACTpro1520eControllerisasingledoorIPcontrollerwitha12VDC2APSU.
Seealso:
l
http://van.fyi/url/ACTpro1520e
1.1 Technical specification
Technical Details
Voltage Range (Controller) 11–24VDC
Current Consumption (Controller) 350mA(Max)
Dimensions (1520e Controller) 235mmx255mmx85mm
Weight (1520e Controller) 950g
Dimensions (1500e Controller) 235mmx165mmx55mm
Weight (1500e Controller) 465g
Relay contacting rating
Mainrelay5A/50VAC,AUXrelay1A/
50VAC
Operating temperature -10to+50°C
Indoor use only
1.1.1 ACTpro 1520e electrical specification
Thepowersupplyiscapableofdelivering2A.1.5Aisavailableforexternallocksandreaders,0.5Aforthe
PCBandbattery.
Electrical Specification
Input Voltage 230VAC+/-10%
Frequency 47-53Hz
Input Fuse 625mA250Vanti-surgefuse
Output Voltage 13.65V(+/-5%)
Max Load 2A@25ºC
Electronic Output fuse Yes
Battery Current ~0.5Aforabatterydischargedto~10V
Battery Protections DeepDischarge/OverCharge/ReversePolarity
