1.1.2 ACTpro 1520e PSU output voltage
Thepowersupplyprovidestwo12Voutputs.Oneispre-wiredtopowertheACTController.Thesecondis
availabletopowerlocksandreaders.
Thefullloadcurrentsharedbetweenthetwooutputs.ACTrecommendthatamaximum of 1.5Aisused
topowerlocksandreaders.Theremaining0.5Aisusedbythecontrollerandbatterycharging.Total
currentfrombothoutputsmustnotexceed2A.SeeACTPro 1520e PSU power budgetonpage7.
1.2 Monitoring
AllfaultsincludingMainsPresentandTamperarereportedontheACTEnterprisesoftwareandviathe
webbrowserontheACTpro1520eand1500econtroller.
Mains
present
FortheACTpro1520eController,thePSUMAINSPRESENToutputispre-wiredtotheMAINS
PRESENTinput.
Output
Voltage
FortheACTpro1520eController,thePSUoutputvoltagelevelisreportedtotheACTEnterprise
softwareandonthewebbrowser.
Tamper Theenclosurelidistampermonitored.
1.3 ACTpro 1520e PSU LED indicators
Green – AC
OK
IndicatesthattheACMainsiswithinspecification.
Amber – ON
BATTERY
Indicatesthatthebatteryissupplyingtheoutputvoltage.
Red – FUSE
FAULT
Indicateselectronicoutputshutdownfuseisactiveandthatnopowerisbeingsuppliedtotheload.
ThemaximumcurrentthatthePSUcanguaranteeis1.5Aplus0.5Aforbatterycharging.Beyond
thisthefusewilltripandtheLEDwillstayonuntiltheloadisfullydisconnected.
Oncetheloadhasbeendisconnected,removedevicestoreducethecurrentdemandbelow1.5A.
Itisimportanttocalculatethepowerbudgetadequately.SeeInstallationonpage7formore
information.
