2 Installation
TheACTpro1520e/1500eControllersareforindoorinstallationonlyandmustbeinstalledaspermanently
connectedequipment.
Anexternalmainsdisconnectdevicemustbefitted.Beforeinstallation,ensurethatthemainssupplyto
thecontrollerisdisconnected.
MainspowershouldbeconnectedtoACTproControllersbyalicensedelectricianinaccordancewith
local/nationalcodes.
2.1 Mounting
MounttheACTproControllerdirectlyontothewallwiththesuppliedscrews.
Thekeyedmountingholeshouldbescrewedfirsttothewalltoaidthemounting.
Theunitshouldbeinstalledinaventilatedareathatallowsforaccessibilityafterinstallation.
2.2 ACTpro 1520e power supply
2.2.1 Mains power up for the ACTpro 1520e
1. Attachacorrectlyratedmainscableandfastenusingthecabletie.
2. Useanapprovedexternalmainsdisconnectdevice.
3. Applymainspower.
4. Checkthatthe‘ACOK’LEDisonandmeasurethe+12Voutput.
2.2.2 Battery insertion for the ACTpro 1520e
1. Disconnectthemains.
2. Ensurethebatteryhasenoughchargetosupplytheload.
3. Connecttheredbatteryleadtothe“+”batteryterminalandtheblackleadtothe“–”terminal.
4. Applythemainspowerandcheckthatthe“ACOK”GreenLEDisilluminated.
5. Removethemainspowerandcheckthatthe“ONBATTERY”AmberLEDisilluminated.Ifthe
AmberLEDisilluminatedthebatteryisnowsupplyingtheoutput.
6. Re-applythemainspower.The“ACOK”LEDwillilluminateandthe“ONBATTERY”LEDwill
extinguish.
2.2.3 ACTPro 1520e PSU power budget
TheACTpro1520eincludesanACT12VDC2Apowersupplyunit.
0.5Aofthe2Aoutputcurrentisusedtopowerthecontrollerandsupplythebatteryrechargecurrent.A
completeaccesscontrolsystemwillrequirereadersandalockmechanism,allofwhichwillrequirepower.
