4 Reader components and package contents
The following diagrams identify the reader components and the contents that come packaged with the reader.
4.1 Reader components
1 Front 6
Location where cables can come
through the back
2 Hook 7 Tamper base
3 Base 8 Screw for tamper protection
4 Gasket 9 Mounting holes
5 Knock outs x 2 10
Upper and lower terminal block
locations
© Vanderbilt 2018 8
A-100410
21.06.2018
