VANMOOF X3 - Wheel Alignment Check; Connecting the Motor Cable

12
BUILD YOUR VANMOOF
7.1 Check both sides of the front fork
dropout to see if the installation is
correct, the anti-theft nut should sit in
the centre of the dropout.
8.2 Identify the motor cable opening (C).
To connect the motor cable both
arrows on the connectors should be
aligned (D).
8.1 Make sure that the motor cable (A)
runs between the motor and fender
stay (B). Double check that the motor
cable is not rubbing on the motor or
wheel.
7. Wheel alignment
8. Connect the motor cable
CA
B
D
Installation correctInstallation incorrect
