15
9.4 Identify the right pedal – if you
stand behind the bike, it’s attached
to the right side of the bike (and
has an engraved ‘R’).
9.5 Screw onto the right crank by hand in a
clockwise direction.
9.6 Tighten the pedal using Allen key #6.
10.1 Hold the front wheel between your
knees and try to rotate the handlebar.
If you can feel any movement, use Allen
key #5 to secure the handlebar.
Check the bolts’ position – the top
should enter from the left, and the
bottom from the right.
10. Check your handlebar
Tighten using
Allen key #6
Screw
Allen key #5
Engraved ‘R’
