30
E
Allen key #5
2. 4 Loosen the bolt (C) and gently slide the
handlebar down (D). Check the height
for comfort.
2. 5 Tighten the two bolts using Allen key
#5, making sure the stem stays in line
with the front wheel (E) and the handle-
bar is aligned with the notches on the
internal stem. Do not over-tighten the
bolts, just turn until they are secure.
Note
When insterting the bolts they need to
remain on the side they were taken out from
left bolt top hole, right bolt bottom hole.
Make sure the handlebars are aligned
with the shim if you cannot insert the bolts
completely this means it is not aligned.
C
D
F
