Vantage Hearth CC-STAT - Installer System Settings Table (Continued)

SECTION TWO - Setup & Testing CC-STAT
©Vantage, 41184 / IS-1308191-A page 14 of 23
Installer System Settings Table (continued)
System setting Description
Factory default setting (bold) and
setting range
19.
THIRD STAGE
DIFFERENTIAL
3rd stage differential.
1°F (0.5°C)
1°F to 9°F (0.5°C to 4.5°C)
20.
FOURTH STAGE
DIFFERENTIAL
4th stage differential.
1°F (0.5°C)
1°F to 9°F (0.5°C to 4.5°C)
21.
INTEGRAL FACTOR
PERIOD
Short period = more
cycles per hour (comfort)
Long period = less cycles per hour
(economical).
2 MINUTES
1 to 5 minutes or “OFF” for proportional
control only
22.
LOW BALANCE POINT Outdoor temperature low balance point
(This option is only displayed if the outdoor
temperature sensor is enabled).
20°F (–6°C)
10°F to 50°F (-12°C to 9°C) or OFF to
ignore
23.
HIGH BALANCE POINT
Outdoor temperature high balance point
(This option is only displayed if the outdoor
temperature sensor is enabled).
65°F (18°C)
40°F to 85°F (3°C to 30°C) or OFF to ignore
24.
EXTENDED FAN – HEAT
Extends fan operation after heat call ends.
DISABLE
ENABLE (90 second extension)
25.
EXTENDED FAN – COOL
Extends fan operation after cool call ends.
DISABLE
ENABLE (90 second extension)
26.
PROGRESSIVE RECOVERY
Enable or disable Progressive recovery.
DISABLE
ENABLE
27.
DEADBAND Auto changeover mode dead band.
3°F (2°C)
2°F to 9°F (1°C to 5°C)
28.
HUMIDISTAT MODE Sets humidity control mode.
HUMIDIFY
DEHUMIDIFY
AUTO
OFF
29.
TEMPERATURE SCALE Set the thermostat to Fahrenheit or Celsius
mode.
FAHRENHEIT
CELSIUS
30.
AUTO DAYLIGHT SAVINGS
Enable or disable auto daylight savings.
OFF
MARCH (second Sunday in March to the
first Sunday in November)
APRIL (first Sunday in April to the last
Sunday in October)
32.
CONSTANT BACKLIGHT
Enable constant, low intensity, backlight when
24VAC is present.
DISABLE
ENABLE
33.
BACKLIGHT INTENSITY
Backlight intensity as a percentage of full on.
100 PERCENT
0 – 100%
34.
SENSOR OFFSET Field adjustment of the controlling
temperature sensor.
0°: No offset applied
–8°F to +8°F (-4°C to +4°C)
35.
PROGRAM FORMAT Select weekly program format.
7-DAY (Mon, Tue, Wed, Thu, Fri, Sat, Sun)
5/1/1 (weekdays, Saturday and Sunday)
5/2 WEEKDAYS (weekdays and weekends)
NON-PROG
36.
EVENT CONFIGURATION
Setting for event naming.
RESIDENTIAL
COMMERCIAL
37.
EVENTS PER DAY Number of program events per day. FOU
R
TWO
38.
USER SECURITY SETUP
Enable or disable security setup system
variables in the User Setup Screens.
DISABLE
ENABLE
39.
SECURITY Enable or disable security.
DISABLE
ENABLE
40.
SECURITY PIN Security pin code.
####
4-digit numeric pin
