IC-610 - Intelligent Control
CHAPTER 2 - INSTALLATION
CHAPTER 2 - INSTALLATION
2.1 UNPACKING
Unpack the IC-610 and inspect contents for damage.
Should the contents appear to be damaged, contact your
local distributor to return the material.
The package should contain the following standard
items:
• 1 IC-610 control
•
1 Power Fuse
•
1 Alarm Fuse
• 1 Temperature probe
•
1 User’s Guide
•
1 Configuration document package including wiring
diagrams and appropriate control settings
The following optional items may be added:
•
Additional temperature/static pressure/humidity
probes
2.2 MOUNTING
The manufacturer recommends that the following
installation instructions be adhered to as closely as
possible, and that all work be performed by a certified
electrician. Failure to do so may void the warranty!
To limit the IC-610’s exposure to noxious gases, install
the unit in a hallway.
Make sure the IC-610 is properly installed, that is, side
up with the cable entry holes facing down (see figure
1).
The IC-610 operates in a temperature range of 32°F to
120°F (0°C to 50°C).
The enclosure is watertight, but not splash proof or
immersion proof. DO NOT WATER the control. Cover it
carefully with plastic when cleaning the room.
It is prohibited to use overhead cables outside the
building.
