Varifan IC-610 - Safety Control Backup Wiring 1

Page 19
Figure 5 Safety Control Backup Wiring 1
8 PIN RELAY DPDT
(OMRON model MK2EP-UA-AC120)
3
4
5
6
2
1
8
7
NO 2
NO 1
NC 1
NC 2
COM 2
COM 1
L2
GND
L1
3
4
5
6
2
1
8
7
DISTRIBUTION
PANEL
L2 L1 GND
LINE
230 VAC
source 1
DISTRIBUTION
PANEL
L2 L1
GND
N
LINE
230 VAC
source 2
IC-610 POWER INPUT
SAFE WIRING WITH SECOND POWER SOURCE
If the 115
VAC line is
used, then
replace L2 by the
Neutral Line as
shown on the
diagram.
1
1
