IC-610 - Intelligent Control
F2:
The probes’ individual values are displayed sequentially.
After 60 seconds, the F1 menu comes back on.
F3:
Displays the recorded highs and lows. Press
simultaneously the + and -buttons for 2 seconds to clear
the highs and lows. The Clr message appears for 2
seconds to confirm the clearing. Then, after 60 seconds,
the F1 menu comes back on.
3.2.5 Supervisor Mode
The supervisor mode allows users to read and ajust all
flashing parameter values by entering a code containing 3
numbers, as indicated in the configuration document.
When the control is not in supervisor mode, certain
parameters are hidden or locked and can not be modified.
However, the flashing ones are not locked and can still be
modified.
CODE ENTRY PROCEDURE
1. Press the lower arrow to access the supervisor mode,
which is normally the last parameter. The LED display
will show if the mode is ON (Su :ON) or OFF (Su :
OFF).
2. If it is OFF, enter the code first by pressing F2. The LED
display shows N: for the value number, then flashing 00
indicating the code values.
3. If the supervisor code is : 45, 12, 05, first enter 45, then
press F2 to access the second code number. Then,
enter 12, followed by F2 and enter the third number
which is 05.
4. Finally, press
F3
to validate the code.
5. If the entered code is correct, the control will switch to
supervisor mode (or switch the mode OFF if it was
already ON) and go back to F1.
6. If the entered code is incorrect, the Err message will
flash during 3 seconds.
CHAPTER 3 - USER’S GUIDE
