Page 36
IC-610 - Intelligent Control
3.3 CONFIGURATION
3.3.1 Dowloading a new configuration
Below is the procedure to download a new configuration
in the IC-610:
a) Turn off the power source on the IC-610 (flip the
circuit breaker on the power distribution pannel).
b) Remove the faceplate screws and lift up the cover.
c) Locate the configuration module (top left-hand
corner) and insert the config. module into the socket
of the main board. Make sure the arrow of the
config. module is pointing the same direction as
illustrated on the main board (see figure 2).
d) Switch on the power source. The display on the
front panel should indicate dnLd for approximately
five seconds. If dnLd is not displayed, try one more
time. If display is still not responding, remove and
replace the config. module. Make sure the arrow of
the config. module is pointing the same way as on
the main board.
e) When the downloading procedure is complete, remove
the config. module and place it in the bottom part of the
enclosure or in another safe location.
CHAPTER 3 - USER’S GUIDE
NOTE :
If the config. module is not removed after the
downloading procedure, the control will reload the
default values each time it is resetted or each time its
power is turned off and back on, erasing the values
entered by the customer.
