06 MAINTENANCE
G4 filter
G4 filter
F7 filter
G4 filter
G4 filter
F7 filter
MAINTENANCE VENTILATION UNIT
CLEANING FILTERS
Vasco recommends cleaning the filters every 3 months.
1. Pull the filter drawer out of the unit.
2. Remove the coarse dust particles with a vacuum cleaner without
damaging the filters.
3. Carefully slide the filter tray back into the ventilation-unit.
FILTER ALERT
The ventilation unit is provided with an automatic filter notification that
indicates when the filters need to be replaced.
The lifespan of the filters is 6 months.
Whenever filter replacement becomes necessary, while operating the
position switch, the LED on the position switch lights up orange
2x consecutively.
REPLACING FILTERS
1. Pull the filter drawer out of the unit.
2. Remove the old filters. If you do not use the bottom or top connection,
do not replace this filter.
3. Insert the new filters. Place the F7 filter in the supply air and the G4
filter in the extracted air.
4. Slide the filter drawer back into the ventilation-unit.
5. Reset the filter alarm by pressing the "position 1" and "timer" buttons
simultaneously for at least 4 seconds, until the LED lights up green.
STANDARD CONFIGURATIO REVERSE CONFIGURATION
LEFT RIGHT
MAINTENANCE
FILTERTYPES
F7/G4 filter
filter G4
filtre G4
filter G7
filter G7
filter G4
filter G4
