3.13.2 INPUT Buffer (Master PLC)
The EtherCAT process data mapping is done automatically corresponding to the following list and respectively to the sync
manager information.
3.13.2.1 Overview
Buffer
Pressure
Pressure sensor 1
Pressure sensor 2 (optional, only in case of 2 sensor version)
Position
Reserved - not used
Control mode
Fatal error
Reserved - not used
Reserved - not used
Reserved - not used
Reserved - not used
General status
General warning
Extended warning
Cluster valve monitoring address – Reserved, optional required
Cluster valve position – Reserved, optional required
Cluster valve control mode – Reserved, optional required
Cluster valve status – Reserved, optional required
Cluster valve warning – Reserved, optional required
