Installation, Operating & Maintenance Instructions
Series 612 DN 250 (I.D. 10”), EtherCAT
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel +41 81 771 61 61 Fax +41 81 771 48 30 CH@vatvalve.com www.vatvalve.com
4.1 Additional EtherCAT warning
Failure detection with CPA or
CV software
Network failure: No EtherCAT
communication is active
(warning 8)
- EtherCAT cable ok?
- Connection to master ok?
- Process data output
watchdog (SyncManager2)
disabled or timing settings
wrong?
- Check EtherCAT cable.
- Check the EtherCAT connection to master.
- Check the process data output watchdog –
SyncManager2 settings (see chapter: «EtherCAT
configuration - 5. EtherCAT process data output
watchdog – SyncManager»).
If you need any further information, please contact one of our service centers. You can find the addresses on our website:
http://www.vat.ch
