15. Appendices
164 vatech A9 (Model name: PHT-30CSS) User Manual
15.2.2 Leakage Dose
X-ray Leakage Dose Test Report for PHT-30CSS maintains dosemetric evaluation of
the Vatech dental diagnostic system to meet requirements in IEC Collateral Standard.
To limit unnecessary exposure to the patient, the operator, and other staff, PHT-30CSS
is designed to fulfill IEC 60601-1 (IEC 60601-1-3, IEC 60601-2-63) and this document
provides a leakage test report with the evaluation condition and procedure.
15.2.2.1 Standard
National Deviation Terminology Permissive Range
International Standard
IEC 60601-1-3
Leakage
limits leakage at 1m from the
source to 100 mR in 1 hr
15.2.2.2 Measurement Overview
15.2.2.3 PANO Mode Results
Test Condition
Tested Mode PANO
Distance from focal point [m] 1
Applied Tube Voltage Peak [kVp] 80
Applied Tube Current [mA] 12
