Vatech A9 User Manual

10. Troubleshooting
120 vatech A9 (Model name: PHT-30CSS) User Manual
10.2 Error Codes
In instances of abnormal operation, error messages appear with error codes on the
Console Software and Control Panel. If a problem persists, please request assistance
from the customer support information services.
Error messages will be displayed in the format written below.
[Code: E00X.0XX.0XX]
The code consists of three parts: Main code, Subcode, Tail
code.
 The main code indicates the source of error codes. The
source is categorized as hardware, software, an
acquisition module, etc.
 Subcode describes the specific area where the error
has occurred according to the main code.
 The tail code explains the specific symptoms and
causes of the errors mentioned in the subcode.
10.2.1 Main code - Hardware (001)
10.2.1.1 Subcode – Generator related error (001)
Tail
code
Description
001 Appears when the tube is not ready for use
002
Appears when the cable between the tube tank and Inverter board are
disconnected
003
Appears when a current of the inverter board exceeds the maximum
allowable level during X-ray irradiation
004
Appears when there is ±10kV or more voltage difference in tube voltage
compared to a reference value
005
Appears when there is ±0.5mA or more current difference in tube
current compared to a reference value
006
Appears when there is ±20kV or more voltage difference in tube voltage
feedback compared to the average value
007
Appears when there is ±1mA or more current difference in tube current
feedback compared to the average value
008
Appears when the temperature of the mono tank is above the setting
temperature
