5. Imaging Software Overview
vatech A9 (Model name: PHT-30CSS) User Manual 43
English
No. Item Description
11
Guide Message
window
Displays various text instructions for the operator.
12
CONFIRM
/READY
button
Applies the selected settings and moves to the next step.
(Exposure parameter setting and patient positioning >
Ready for exposure)
When you click the CONFIRM button, estimated DAP
(Dose Area Product), scan time, and exposure time would
be displayed DAP, Scan Time, and Exposure Time
Display window.
It is activated when you click the CONFIRM button after
the patient positioning is completed. Click the button
when all aspects of preparation are completed for image
acquisition.
13 X-ray intensity
Selects X-ray intensity.
Depending on the circumference of the patient’s head, X-
ray intensity may be classified as Hard, Normal, or Soft:
Soft ≤ Normal ≤ Hard
14
Patient’s
gender/age
group
Displays the current patient’s gender/age group as
entered in EzDent-i’s patient information fields. If
necessary, the gender/ age group can be manually
selected.
