7. Acquiring PANO Images
vatech A9 (Model name: PHT-30CSS) User Manual 57
English
1. Click the PANO button on the Main Screen.
The CEPH button exists only when the CEPH imaging
program is included in the equipment.
2. Make an Arch Selection.
Arch Selection Description
Narrow
Panoramic image of V-shaped palatal arches
(Small number of adult females)
Normal Panoramic image of normal adult palatal arches
Wide
Panoramic image of square-shaped palatal arches (some
number of adult males)
Orthogonal
The panoramic image where the x-ray angle enters vertically
in between the teeth, so overlapping images is minimized.
If Orthogonal Arch is selected,
Bitewing examinations (Bitewing,
Bitewing Incisor (Optional),
Bitewing Right, Bitewing Left) are
activated.
Child
Panoramic image of child palatal arches, more than 40% less
X-ray dose than in Normal mode.
