7. Acquiring PANO Images
vatech A9 (Model name: PHT-30CSS) User Manual 59
English
5. Select X-ray intensity.
Depending on the circumference of the patient’s head, X-
ray intensity may be classified as Hard, Normal, or Soft:
Soft ≤ Normal ≤ Hard
6. The values of tube voltage and current are configured automatically according to
the patient's gender/age group and X-ray intensity. Click the UP/DOWN arrow to
adjust kVp and mA. The dose is adjustable by ±1 kVp and ±1 mA, respectively.
7. Click the CONFIRM button when the exposure parameter setting is completed.
When you click CONFIRM button,
 The Rotating Unit will move to its initial scanning
position.
 The Vertical Beam will be activated to make patient
positioning easier.
 The DAP (Dose Area Product), Scan Time, and
Exposure Time will be displayed below the Scan
Information window.
8. Guide the patient to the equipment.
