Vatech A9 User Manual

7. Acquiring PANO Images
vatech A9 (Model name: PHT-30CSS) User Manual 63
English
6. Adjust the instrument to the patient's sitting height using the Column UP/DOWN
on the Handle frame or the optional UP/DOWN switch while the patient holds the
handle.
7. Close contact patient's chest to the handle frame.
8. Maintain the position described below.
 Hold the handle firmly.
 Make sure the patient's chest is in contact with the equipment.
 Keep both shoulders parallel.
 Straighten the patient's cervical spine and sit still.
 Let the patient bite the Bite along its grooves with his/her front teeth.
9. Let the patient maintain the position described below.
• Close the mouth.
• Place the tongue on the roof of the mouth.
• Close the eyes.
