8. Acquiring CEPH Images (Optional)
vatech A9 (Model name: PHT-30CSS) User Manual 81
English
1. Click the CEPH button on the Main Screen.
The CEPH button exists only when the CEPH imaging
program is included in the equipment.
2. Select an Image Option.
3. Select an examination program in the CEPH Examination panel.
4. The Gender/Age group of the patient is selected automatically based on the patient
information. If necessary, you can select the option manually.
