14. Technical Specifications
vatech A9 (Model name: PHT-30CSS) User Manual 151
English
14.2.2 Detector Specifications
Item
Description
PANO & CBCT CEPH
Model Xmaru1404CF-Plus Xmaru2602CF
Detector Type CMOS photodiode array
Pixel size 198 µm @ 4x4 binning 200 µm @ 2x2 binning
Active area 135.8 x 36.4 (mm) 259.2 x 15.6 (mm)
Frame Rate ~ 308 fps @ 4x4 binning ~330 fps @ 2x2 Binning
Analogue-Digital
Conversion
14 bits
Operating condition
10~35 ℃ (Temperature)
10~75 % (Humidity)
Storage condition
-10~60 ℃ (Temperature)
10~75 % (Humidity)
Sensor size
160(L) x 230(W) x 26(H)
(mm)
110(L) x 279(W) x 20(H)
(mm)
Sensor weight 1.5 kg Less than 1.3 kg
Converter Csl : Ti
Energy Range 50~120 kVp
Readout Charge amplifier array
Video Output Optic
MTF > 45 % @ 1 lp/mm > 8 % @ 2.5 lp/mm
DQE > 60 % @~0 lp/mm > 70 % @~0 lp/mm
Dynamic Range
> 80 dB > 70 dB
