5. Imaging Software Overview
44 vatech A9 (Model name: PHT-30CSS) User Manual
No. Item Description
15
Modality
Selection
button
Selects the imaging parameters for each mode: PANO,
CEPH (Optional), and CBCT Scan
Selecting Modality changes the Modality Selection screen
to the Imaging Parameters Configuration panel.
16 EXIT button Exits the console software.
After completing the X-Ray survey, a pop-up message
appears to show the progress of the image acquisition and
display a preview of the acquired image.
