PaX-i3D Green (PHT-60CFO) User Manual
140
12 Technical Specications
Item Description
Weight (kg)
Without CEPH
unit
Without base: 127 (280.0 lbs)
With base: 182 (401.2 lbs)
With CEPH unit
(Scan Type)
Without base: 157 (346.1 lbs)
With base: 212 (467.4 lbs)
With CEPH unit
(Oneshot Type)
Without base: 167 (368.2 lbs)
With base: 222 (489.4 lbs)
Total Height (mm)
Without base: Max. 2,320 mm (91.34 inch)
With base: Max. 2,345 mm (92.32 inch)
Vertical column movement (mm) Max. 700 (Max. 27.56 inch.)
Length x
Width (mm)
Without
CEPH unit
1,200 (L) x 1,325 (W) mm
47.24 (L) x 52.17 (W) inch
With CEPH unit
(Scan Type)
1,985 (L) x 1,325 (W) mm
78.15 (L) x 52.17 (W) inch
With CEPH unit
(One shot Type)
1,985 (L) x 1,325 (W) mm
78.15 (L) x 52.17 (W) inch
Type of installation Base Stand / Wall Mount
12.2
Technical Specications
X-ray Generator
Item Description
Model DG-07C11T2 DG-07C11C1
Rated output power 1.6 kW (1 sec)
High
voltage
generator
Type Inverter
Normal/
Pulse
kVp 50 ~ 100 ( 1 kV step)
mA 4 ~ 16 ( 0.1 mA step)
Cooling
Automatically controlled / Protect ≥ 60
℃
Air Cooling: Optional
Added Filtration 2.0 mmAl 2.3 mmAl
Total ltration 2.8 mm Al eq.
X-ray tube
Manufacturer Toshiba CEI
Model
D-052SB
(Stationary Anode
Type)
OPX/105
Tube voltage Operating 50-100 kV _
Tube current Maximum 22 mA _
