PaX-i3D Green (PHT-60CFO) User Manual
54
4 Software Overview
Exposure Time (Max. 20.2 s)
Examination Arch Selection Examination Mode
Scan Time (s)
HD Normal
PANO
Examination
Narrow
Standard 13.5 10.1
Front 11.1 8.4
Right 6.7 5.1
Left 6.7 5.1
Normal
Standard 13.5 10.1
Front 11.1 8.4
Right 6.7 5.1
Left 6.7 5.1
Wide
Standard 13.5 10.1
Front 11.1 8.4
Right 6.7 5.1
Left 6.7 5.1
Child
Standard 11.5 8.6
Front 9.2 6.9
Right 5.7 4.3
Left 5.7 4.3
Orthogonal
Standard 13.5 10.1
Front 11.1 8.4
Right 6.7 5.1
Left 6.7 5.1
Bitewing 9.6 7.2
Bitewing Right 4.8 3.6
Bitewing Left 4.8 3.6
Special
Examination
TMJ LAT Open
6.1 4.6
TMJ LAT Close
TMJ PA Open
7.0 5.3
TMJ PA Close
Sinus LAT 6.0 4.5
Sinus PA 10.3 7.7
NOTE
-
: Indicates that the examination supports Magic PAN.
- Maximum exposure time deviation: ± 10 % (IEC 60601-2-7)
