PaX-i3D Green (PHT-60CFO) User Manual
58
4 Software Overview
C. Horizontal Position
This selects the horizontal imaging region:
Right, Center, or Left.
Guidance Image FOV (mm) ROI
160 X 100 Mn - Center
150 X 150 Mn - Center
120 X 90 Mn - Center
100 X 80 Mn - Center
80 X 80 Mn - Center
80 X 50 Mn - Center
50 X 50
Mn / Left Central
Incisor
4. Image Quality
Model Mode Scan Time
MaX FOV 100 x 80 High Resolution/Green
9.0/5.9 s
MaX FOV 160 x 100 High Resolution/Green
9.0/5.9 s
MaX FOV 150 x 150 High Resolution/Green
15.0/9.0 s
