ELCARE NORDIC: service.vaya@elcare.com
4. Adjust seat, handlebar and stem to user preference.
WARNING: After unfolding the bike, make sure to check all the safety locks. Please pay
extra attention to closing the safety lock of the frame and the head tube to ensure safety.
LCD DISPLAY
77
55
66
11
33
44
22
1. BATTERY INDICATOR
Shows how much battery capacity is left. Remember to charge the battery when it
is low on power. The motor will slowly begin to feel weaker as the battery power
indicator goes down.
2. MULTIFUNCTION DISPLAY AREA
Shows different settings. Refer to section OPERATING PRINCIPLES for
further information.
3. SPEED
Shows the current speed.
4. PADDLE ASSIST SYSTEM (PAS)
Shows the PAS gear.
5. MOTOR POWER INDICATOR
Shows the current motor power output.
6. USB CONNECTION ICON
If the icon is displayed then the display is connected to a USB device.
7. LIGHT INDICATOR.
OPERATING PRINCIPLES
• Press and hold the ON/OFF button to power the e-bike on or off.
• Short press the + button to increase the pedal assist gear.
• Short press the – button to decrease the pedal assist gear.
• Press and hold the
button for 2 seconds to turn on/off the front and rear lights. If
the
icon is displayed, the lights are turned on.
• Press the button to switch between high beam and low beam on front light.
• Press and hold the – button to activate the walk assist. It will start after 2 seconds.
