As soon as you release the – button the walk assistance is turned off. The
icon is
displayed when walk-assist mode is activated.
• Short pressing the ON / OFF button will show different display settings:
o ODO: Total accumulated mileage riding the e-bike.
o MAX. SPEED: Maximum achieved speed.
o AVG. Speed: Average speed while using the bike.
o Time: Shows how long the e-bike has been turned on.
• Trip is always shown on the display:
o TRIP: Distance driven since powering on the e-bike.
• If not used for 10 minutes, the bike will automatically power off.
• If an error occurs on the electrical system, the
icon with an error code is
displayed. See the section “Display error description” for more information.
SETTINGS
Simultaneously press and hold the + and – buttons for 2 seconds to enter the display settings.
Press the ON / OFF button to enter/conrm settings. Press the + / – buttons to switch
between settings or to change settings.
Press and hold the ON / OFF button for about 1 second to save the selected setting and exit
the settings menu.
If not used for 1 minute, the display will automatically exit the settings menu.
Main menu
Here you select Display settings and advanced settings.
Display settings
• Trip Reset: Select YES to reset the trip value; select No to cancel.
• Toggle Unit: Select between Imperial (mil) and Metric (km).
• Wheel: Set the wheel size in inches.
• LCD Luminance: Set display background brightness level. 0 - 100 %
• SOC View: Set battery indicator on display. Select between showing battery indicator
in percentages or in volts.
• Factory Restore: set to yes to reset to default settings.
• Password: Here a password can be created. When activated, the password must be
entered every time the bike is powered on. See the section “Password”.
• BACK: Return to the main menu.
Advanced settings
• Power set: Set the range of PAS gears to choose from when using the bike and speed
for each gear.
• Set Voltage: Standard volt setting. Check the battery voltage indicator before
changing this setting.
• Current Limit: Set the current limit. Low for less motor output. This will reduce battery
usage and increase the driving range. Increasing the current limit will give more
power to the motor but will deplete the battery faster.
• Speed Limit: Set the max motor speed.
• Assistant Num: Set the number of magnets in sensor disc.
• Speed Sensor: Set the number of magnets in motor.
• Sensitivity: Number of magnets in the magnet disc (located at the crank) that need to
be passed by the sensor before the motor is activated. At a lower setting, the motor
will activate faster.
WARNING: Be aware that if set low, the crank only needs to be turned slightly to
activate the motor. The bike is very heavy, and it can result in a dangerous situation if
the motor is accidently activated.
