Vaya BUDDY-2 - E-BIKE SPECIFICATIONS; RECOMMENDED TORQUES

ELCARE NORDIC: service.vaya@elcare.com
E-bike specications
Net weight: 27,4 kg
Max load: 100 kg
Size (folded): 103 x 59 x 78 cm
Size (unfolded): 180 x 65 x 78 cm
Wheel size: 20 x 4 inch
Max compatible wheel size: 20 x 4 inch
Protection rating: IP54
Number of bike gears: 8
Number of assist mode gears: 5 / 9
Max pedal assist speed: 0 - 25 km/h
Operating range: Up to 50 km
RECOMMENDED TORQUES
PART TORQUE (NM)
Front wheel bolt 28 - 32 Nm
Rear wheel bolt 30 - 35 Nm
Handlebar clamps 5 - 8 Nm
Adjusting nuts 12 - 15 Nm
Seat bolts 16 - 18 Nm
Brake cable bolt 20 Nm
Brake mounting bolt 12 - 15 Nm
Seat post nuts 16 - 18 Nm
Crank 35 - 40 Nm
Folding handle 6 - 8 Nm
Flange mounting screw 3 - 5 Nm
Rear derailleur 6 - 9 Nm
Sprocket holder screw 35 - 40 Nm
Gear change holder screw M5 5 - 7 Nm
Brake disc screw M5 20 - 22 Nm
Support base 10 - 12 Nm
Battery connecting screw 5 - 7 Nm
Handbrake 5 - 8 Nm
26
