Vdwall LVP300 - Test Pattern Generation; Input Video Signal Setting

LVP300 LED HD Video Processor
20
3
）
Test pattern
LVP300 can generate 36 test patterns for LED screen testing.
If this item value is “off”, turn off Test pattern. Select other number and confirm.Then
one corresponding test pattern of 36 pcs will be selected.
Operation steps
：
Press ↓ button to select“1.6 Test pattern” item，then rotate knob to select suitable test
pattern number and press ”OK” to apply the test pattern.
--------------------------------------
1.1 Resolution 1920x1080_60
1.2 Out Width 1920
1.3 Out Heith 1080
1.4 Out H_Start 0
1.5 Out V_Start 0
1.6 Test pattern 0 - >5
Note：The current signal must connect valid input. Then the test pattern has output.
Otherwise no output.
2. Input video signal setting
Press Setup button to enter setup menu. Press↓ button to select 2. Input video signal
and press OK to enter this item.
2. Input video signal
--------------------------------------
2.1 DVI EDID 1280 x1024_60
2.2 Switch mode one key switch
