ISD Alarm Message Diagnostics hnn: VPRFLOW MTR SETUP
24
hnn: VPRFLOW MTR SETUP
Incoming transaction from a hose with an unavailable Vapor Flow Meter.
ISD MONITORING CATEGORY
ISD Setup Diagnostic self-tests (ref. page 17) are designed to monitor and ensure proper monitor configuration.
Setup self-test will verify at least one Vapor Flow Meter is setup.
DIAGNOSTIC PROCEDURE
1. Using the ISD Hose Setup Menus print out the ISD Hose Table (see example printout below).
2. Find the AFM assigned to Hose nn.
3. Verify that the AFM is still configured in the TLS.
hosetableprtout.eps
ID = Hose ID
FP = Mapped fuel position as TLS Console recognizes it
(-1 = unassigned)
FL = Fuel position label as written on dispenser
HL = Hose label
AA = Airflow meter ID assigned
RR = Relay ID
UU = unassigned
ID = Airflow meter ID assigned
Serial Number = Airflow meter's
serial number
ISD HOSE TABLE
ID FP FL HL AA RR
------------------------
01 01 01 02 01 UU
02 02 02 02 01 UU
03 03 03 02 02 UU
04 04 04 02 02 UU
05 05 05 02 03 UU
06 06 06 02 03 UU
07 07 07 02 04 UU
08 08 08 02 04 UU
09 09 09 02 05 UU
10 10 10 02 05 UU
11 11 11 02 06 UU
12 12 12 02 06 UU
ISD AIRFLOW METER MAP
ID SERIAL NUM LABEL
------------------------
1 03001401 AFM1 FP1 -
2 03001402 AFM2 FP3 -
3 03001403 AFM3 FP5 -
4 03001404 AFM4 FP7 -
5 03001405 AFM5 FP9 -
6 03001406 AFM6 FP11
To Next Page
