Veeder-Root TLS-350R PLUS Troubleshooting Guide

1
Introduction
This manual contains troubleshooting procedures for Veeder-Root In-Station Diagnostics (ISD).
Contractor Certification Requirements
Warranty Registrations may only be submitted by selected Distributors. Certified installers are required to
provide the GDF operator with the completed Equipment Warranty Notice, form 577013-868, for their records.
Related Manuals
577013-800 ISD Install, Setup and Operation Manual (TLS-350 Consoles)
577013-842 ISD Quick Reference Guide
577093-796 Vapor Flow Meter Installation Manual
577093-797 Pressure Sensor Installation Manual
576013-635 Veeder-Root Serial Interface Manual
576013-818 TLS-3XX Troubleshooting Manual (Feature / Version list Section 3, Table 3.-3)
577013-948 PMC Install, Setup & Operation Manual For Veeder-Root Vapor Polishers (TLS-350 Consoles)
577013-801 PMC Install, Setup & Operation Manual For VST ECS Membrane Processors (TLS-350 Consoles)
577013-937 ISD Install, Setup & Operation Manual for VST ECS Membrane Processors and Veeder-Root Vapor
Polisher (TLS-350 Consoles)
577013-920 Carbon Canister Vapor Polisher Installation Manual.
Veeder-Root Contractor
Certification Requirements
Installer
Certification
6
ATG Technician
Certification
7
VR Vapor Prod-
ucts Certification
8
Install
1
ISD
X X X
Install PMC
X X X
Install CCVP
X X X
Install Wireless ISD/PMC
X X X
Installation Checkout
2
X X
ATG Startup
3
/ Training
4
/ Service
5
X X
ISD Startup / Training / Service
X
PMC Startup / Training / Service
X
CCVP Startup / Training / Service
X
Wireless ISD/PMC Startup / Training / Service
X
Install Pressure Sensor (ATG)
X X X
Maintain Pressure Sensor (ATG)
X X
Calibrate Pressure Sensor (ATG)
X X
Clear ATG Pressure Sensor Alarm (ATG)
X X
Clear ISD/PMC Alarms (ISD/PMC)
X
1
Perform wiring and conduit touting; equipment mounting
2
Inspect wiring and conduit routing; equipment mounting
3
Turn power on, program and test the systems
4
Provide supervised field experience in service techniques and operations
5
Troubleshoot and provide routing maintenance
6
UST Monitoring Systems – Installer (Level 1)
7
Certified UST Monitoring Technician
8
VR Vapor Products
