MINITRAC 31 • Foundation Fieldbus
41782-EN-211203
Priority Description User Error Codes NE-107 Status
25 Paramererizationerror 16, 17, 25, 52, 53, 57, 66, 117,
120
FAILURE
24 ConictinMGC 121, 122, 141 FAILURE
23 Communication error in MGC 8 FAILURE
22 MGC secondary reports error 38 FAILURE
21 Undened21 - -
20 Undened20 - -
19 Undened19 - -
18 Detector temperature critical 125 OUT_OF_SPEC
17 Errorwhileauto-standardization 73 FAILURE
16 Excessive radiation 123, 124 FAILURE
15 Input out of bounds 13 OUT_OF_SPEC
14 Errorwhilesignalprocessing 68 FAILURE
13 Undened13 - -
12 Undened12 - -
11 Undened11 - -
10 Undened10 - -
9 Undened9 - -
8 Undened8 - -
7 AITB simulated 29 FUNCTION_CHECK
6 Undened6 - -
5 Undened5 - -
4 Undened4 - -
3 Undened3 - -
2 Undened2 - -
1 Errorwhiletrendrecording 126, 127 GOOD
0 Reserved - Reserved
Not displayed 33, 45, 71, 86 -
11.3 Dimensions
Thefollowingdimensionaldrawingsrepresentonlyanextractofallpossibleversions.Detailed
dimensionaldrawingscanbedownloadedatwww.vega.com/downloads under " Drawings".
