VEGAPULS 6X
66216-EN-220518
SiBa20/150a/ALU50 SiBa/-a
Flammability Fire-proof Fire-proof
For measurements with insulation, a layer thickness of 8 cm SiBa 20/150a was applied. Look-
ing from the surface of the tank, a 6 cm layer of SiBa 20/150a was rst applied. A 2 cm layer of
SiBa 20/150a/ALU50 was then nally applied on top of this layer.
Max.surfacetemperatureT
sur
ofVEGAPULS6Xwhenusedinexplosiveatmosheres:
EPLDainstrument-Completedevice(antennaandhousing)installedinZone20(sur-
roundedby200mmdust):
Max. permissible ambient/process temperature: +65 °C
Surface temperature: Ambient/Process temperature +35 K
Max. surface temperature: = 65 °C + 35 K = 100 °C
EPLDbinstrument-Completedevice(antennaandhousing)installedinZone21(without
dustlayer):
Max. permissible ambient/process temperature: +65 °C
Surface temperature: Ambient/Process temperature +35 K
Max. surface temperature: = 65 °C + 35 K = +100 °C
EPLDa/Dbinstrument-HousinginstalledinZone21withoutdustlayer,antennainstalled
inZone20:
VEGAPULS6Xwithplastichornantenna,PS6X(*).2*W**B*AT/AU/AV************
Electronics
housing
Permissibleprocess
temperaturerange
ontheantennain
zone 20
Permissibleambient
temperaturerange
inZone21onthe
electronicshousing
Surfacetemperature
oftheelectronics
housing
Max.surfacetem-
perature
Aluminium
A, D, H, S
-40 … +76 °C -40 … +65 °C Ambient temperature
+35 K
+100 °C
Stainless steel
V, W
-40 … +76 °C -40 … +65 °C Ambient temperature
+35 K
+100 °C
VEGAPULS6Xwithangewithplasticplatingorwithintegratedantennasystem(thread-
edconnection)forprocesstemperaturesuptomax.+150°C,PS6X(*).2*W**F*AW/AY/
A2************,PS6X(*).2*W**T*AA/AC/AE/AG/AJ/AL************
Electronics
housing
Permissibleprocess
temperaturerange
ontheantennain
zone 20
Permissibleambient
temperaturerange
inZone21onthe
electronicshousing
Surfacetemperature
oftheelectronics
housing
Max.surfacetem-
perature
Aluminium
A, D, H, S
-xx … +130 °C -40 … +57 °C Ambient temperature
+35 K
+132 °C
-xx … +150 °C -40 … +48 °C Ambient temperature
+35 K
+152 °C
