Vega VEGAPULS 6X Safety Instruction

14
VEGAPULS 6X
66216-EN-220518
Electronics
housing
Permissibleprocess
temperaturerange
ontheantennain
zone 20
Permissibleambient
temperaturerange
inZone21onthe
electronicshousing
Surfacetemperature
oftheelectronics
housing
Max.surfacetem-
perature
Stainless steel
V, W
-xx … +130 °C -40 … +47 °C Ambient temperature
+35 K
+132 °C
-xx … +150 °C -40 … +34 °C Ambient temperature
+35 K
+152 °C
xx °C lower temperature in the process, limited by the sealing type with xx:
•
AA PEEK/FKM (SHS FPM 70C3-GLT) / -40 … +150 °C
•
AC PEEK/FFKM (Kalrez 6230) / -15 … +150 °C
•
AE PEEK/FFKM (Kalrez 6375) / -20 … +150 °C
•
AG PEEK/FFKM (Perlast G75B) / -15 … +150 °C
•
AJ PEEK/FFKM (Perlast G74S) / -15 … +150 °C
•
AL PEEK/EPDM (A+P 70.10-02) / -55 … +150 °C
•
AW PTFE/PTFE / -60 … +150 °C
•
AY PTFE (8 mm)/PTFE / -60 … +150 °C
•
A2 PFA (8 mm)/PFA / -60 … +150 °C
VEGAPULS6Xwithangewithplasticplatingorwithintegratedantennasystem
(threadedconnection)orwithlensantennaforprocesstemperaturesuptomax.
+195°C,PS6X(*).2*W**F*AX/AZ/A3/A4/A5************,PS6X(*).2*W**T*AB************,
PS6X(*).2*W**C*AB************,PS6X(*).2*W**C*AB************
Electronics
housing
Permissibleprocess
temperaturerange
ontheantennain
zone 20
Permissibleambient
temperaturerange
inZone21onthe
electronicshousing
Surfacetemperature
oftheelectronics
housing
Max.surfacetem-
perature
Aluminium
A, D, H, S
-40 … +130 °C -40 … +65 °C Ambient temperature
+35 K
+132 °C
-40 … +195 °C -40 … +62 °C Ambient temperature
+35 K
+197 °C
Stainless steel
V, W
-40 … +130 °C -40 … +65 °C Ambient temperature
+35 K
+132 °C
-40 … +195 °C -40 … +49 °C Ambient temperature
+35 K
+197 °C
VEGAPULS6Xwithlensantennaforprocesstemperaturesuptomax.+150°C,
PS6X(*).2*W**C*AA/AC/AE/AG/AJ/AL************
Electronics
housing
Permissibleprocess
temperaturerange
ontheantennain
zone 20
Permissibleambient
temperaturerange
inZone21onthe
electronicshousing
Surfacetemperature
oftheelectronics
housing
Max.surfacetem-
perature
Aluminium
A, D, H, S
-xx … +130 °C -40 … +65 °C Ambient temperature
+35 K
+132 °C
-xx … +150 °C -40 … +58 °C Ambient temperature
+35 K
+152 °C
