4 Interface
4.1Boot interface
Boot logo interface is displayed for 2 seconds after the display is turned on. When the
communication connection is established, display enters the main interface which shows information
obtained from the controller. ( All data displayed is following communication protocol provided by
the customer) 。
4.2 Basic interface and operation
M button
Adjust up
& down
Basic display interface
DM05C
RM01
Power-
on
button
To Next Page
