5. CONTROLS (CONT’D)
15
Once the control(s) connection has been made, insert the terminal connector under the unit,
on the recessed side of the electrical compartment.
VD0207
TERMINAL
CONNECTOR
5.2.3 20-MINUTE LIGHTED PUSH BUTTON OPTIONAL AUXILIARY CONTROL
(PRO250 & PRO 225)
NO C NC I OC OL Y R G B
VE0185
ON
5.2 CONTROLS CONNECTION TO THE UNIT (CONT’D)
5.2.2 11136 MAIN CONTROL (PRO225 ONLY)
NO C NC I OC OL Y R G B
VE0190
% RELATIVE HUMIDITY
% HUMIDITÉ RELATIVE
0FF
55% 10 °
45% 0 °
35% -10 °
30% -20 °
%HUM. RELATIVE HUM EXT. TEMPS. ° C EXT.
20
30
40
50
60
70
80
25
-30˚C
-20˚C
5˚C+
-5˚C
